TYM T494C - Table of Contents

TABLE OF CONTENTS
GENERAL INFORMATION
1
1. EXTERIOR VIEW (NON CAB MODEL) ......... 1-2
2. EXTERIOR VIEW (CABIN MODEL) ............... 1-4
3. S
AFETY SIGNS ............................................. 1-7
DESCRIPTION OF TRACTOR
CONTROLS
2
1. INSTRUMENT AND SWITCHES
(NON CAB TYPE) ....................................... 2-2
2.
INSTRUMENT AND SWITCHES
(CABIN TYPE) ............................................. 2-3
3. OPERATING METHOD ................................ 2-14
4.
INSTRUMENT PANEL LAMP AND BUZZER
OPERATING CONDITIONS ...................... 2-15
5. OPERATING THE CONTROLS ................... 2-18
6.
OPERATING THE 3 POINT LINKAGE
(TPL) (NON CAB MODEL) ........................ 2-33
7. OPERATING THE 3 POINT LINKAGE
(CABIN MODEL) ....................................... 2-34
OPERATION
3
1. ENGINE STARTING ....................................... 3-2
2. ENGINE STOPPING ...................................... 3-3
3. ENGINE IDLING ............................................. 3-3
4. RUNNING-IN PERIOD ................................... 3-4
5. STARTING OFF, SHIFTING AND DRIVING ... 3-4
6.
TURNING IN FIELD ....................................... 3-5
7. STOPPING AND PARKING ............................ 3-5
8. DRIVING ON SLOPE ..................................... 3-6
9.
CAUTIONS FOR DRIVING INTO
/ OUT OF FIELD .......................................... 3-7
10. LOADING TO / UNLOADING FROM TRUCK .. 3-7
1
1. CAUTIONS FOR DRIVING ON ROAD ......... 3-8
12. OPERATION CHECK DURING DRIVING .... 3-8
WORK PROCEDURE
4
1. PRECAUTIONS FOR HANDLING IMPLEMENT ..... 4-2
2. GENERAL IMPLEMENT................................. 4-2
