DESCRIPTION OF TRACTOR CONTROLS
1
2
2 - 25
SEAT AND SAFETY BELT
(1) Seat sliding
The seat can be adjusted by moving
it forwards and backwards with the
seat sliding lever on its front pushed
to the left. After adjustment, make
sure that the seat is firmly secured.
(2) Seat belt
Before driving, adjust the
belt's length to fit to your
body and insert it into its
buckle. When it is engaged
properly, a clicking sound
is heard.
►
45NO235A
Seat Sliding
Make sure to wear your seat
belt to protect yourself from a
possible rollover or crash acci-
dent.
Never adjust the seat during
driving.
•
•
WARNING
PTO ON/OFF SWITCH
Operation for 'automatic' and 'man-
ual' position of the PTO selection
switch is as follows:
「ON」
When Pressing the switch, the red
lamp comes on and the PTO shaft
ratates.
「OFF」
When pressing the switch again,
the lamp goes off and the PTO shaft
stops ratating.
►
45NO236A
PTO ON/OFF
Switch
