DESCRIPTION OF TRACTOR CONTROLS
1
2
2 - 9
Fuel level warning lamp
(4) Fuel level warning lamp
If keep i n g d r ivi n g w i t h t h e
n e e d l e o f t h e f u e l g a u g e
pointing at 'E,' the warning lamp
comes on which means there is
only approx. 5 liters of fuel left
in the tank.
(2) High beam lamp
This comes on when the high
beam is turned on.
High beam lamp
Low beam lamp
Tractor turn signal indicator
(1) Tractor turn signal indicator
This lamp is used to indicate
the intended turning direction of
the driver. When pulling down
the turn signal switch, the left
turn signal lamp blinks. When
pu sh in g u p t h e t ur n s i g n a l
switch, the right turn signal
lamp blinks. These lamps are
operated when pressing the
hazard warning lamp switch as
well.
(3) Low beam lamp
This comes on when the low
beam is turned on.
