DESCRIPTION OF TRACTOR CONTROLS
2 - 22
45NO232A
Sub Shift Lever
When the range shift lever is
placed in the position "H," the
driving speed increased. There-
fore, never put the range shift
lever in the position "H" during
driving backwards.
•
WARNING
Operate the range shift lever
only after the tractor is com-
pletely stopped and with the
clutch pedal depressed. Shift-
ing the lever during driving can
damage the gears.
•
NOTE
SUB SHIFT LEVER
The driving direction can be se-
lected between forward direction
and reverse direction using the
shuttle shift lever and range shift
lever.
Use the throttle lever to increase/
decrease the engine speed.
►
•
•
45NO231A
(Low Speed)
(High Speed)
(Neutral)
45NO230A
MAIN GEAR LEVER
This lever can be shift-
ed by using the clutch,
both when the tractor is
stationary or mobile.
It is lo ca te d o n t h e
R.H.S of the driver seat.
►
Main Gear Lever
1 3
2 4
To Next Page
