TYPHOON Q500+, CGO2+ And ST10+ Overview
TYPHOON Q500+ / CGO2+
1 CGO2+ Gimbal Camera
2 Camera LED Status Indicator
3 Camera Lens
4 5.8GHz Antenna
5 Main LED Status Indicator
6 Power Switch
ST10+
7 Proporonal Control Rate Slider
8 USB Connector/Charging Port
9 Audio/Earphone Jack
10 Take Sll Photo Buon
11 Start/Stop Motors Buon
12 Rudder/Yaw Control
13 Throle/Altude Control
14 5.8GHz Antenna (located inside the case)
15 Status Indicators (for ST10+ baery, 5.8GHz WiFi
and GPS)
16 2.4GHz Antenna (located inside the handle)
17 Start/Stop Video Recording Buon
18 Flight Mode Selecon Switch
19 Aileron/Roll Control
20 Elevator/Pitch Control
21 Power Switch
22 Volume and Navigaon Touch-Acvated Buons
(Volume Down/Volume Up/Menu/Home/Back)
23 CGO2+ Pitch Angle/Posion Control Slider
24 SD Card Slot (located under the baery)
The ST10+ is equipped with an internal cooling fan and components that deliver vibrang and
audible alerts.
IMPORTANT NOTE: Although the ST10+ is equipped with digital ‘trims’ (located below the control
scks) they are not acve/funconal when controlling TYPHOON.
