TYPHOON Q500+ - Page 27

Step 9) Rotate the aircra 45
degrees to the le. Then slowly
rotate the aircra 360 degrees
toward the north (as illustrated)
unl it's flat and upright in your
hands again.
IMPORTANT NOTE: If compass calibraon fails the main LED status indicator will glow solid white and you must restart the calibraon process.
Step 11) If you hear an audible
indicaon aer the main LED
status indicator stops blinking
rapidly you have successfully
completed compass calibraon.
Step 10) The main LED status
indicator should be flashing red and
green rapidly (5 mes per second).
Hold the aircra as sll as possible
unl it main LED status indicator
stops blinking rapidly.
IMPORTANT NOTE: Steps 6 to 9
must be completed in less than 30
seconds in order to successfully
complete compass calibraon.
