Ultimaker 2+ Manual

Ver. 01NL okt19
4
MAKERS LAB
Benno Premselahuis
Rhijnspoorplein 1
1091
GC Amsterdam
Removing and introducing material
Switch on the printer with the switch
on the back to the left.
Twist the knob on front and select
MATERIAL.
Press the button.
Select CHANGE and press the
button.
The printing head will be heated up
to prepare for removing the
material.
The material will then be retracted
through the Bowden tube.

Ultimaker 2+ Specifications

General

Build Volume	223 x 223 x 205 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Print Speed	30 - 300 mm/s
Connectivity	USB, SD Card
Weight	11.3 kg
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, CPE
Display	LCD
Software	Cura
Power Supply	100 - 240 VAC, 50 - 60 Hz
Operating Temperature	15 - 32 °C
Dimensions	342 x 588 mm
