Setting up the pipe characteristics
Ext. diameter
Pipe external diameter setting
Ext. Diameter
00048,30 mm
Min : 10,00 mm
Max : 10000,00mm
Ext. circumference
Possibility to set the circumference instead of the diameter
Ext. circumference
00069 ,12 mm
Min : 18,85 mm
Max : 31415,93 mm
Thickness
Pipe thickness setting
In case of homogeneous multi-layer pipe: Ability to set 3 dierent
thickness for 3 dierent material in «Advanced» mode only.
Thickness
003,20 mm
Min : 00,00 mm
Max : 500,00 mm
Material
Pipe thickness setting
In case of homogeneous multi-layer pipe: Ability to set 3 dierent mate-
rial in «Advanced» mode only.
Material
Polyethylene
PVC
PVC HP (rigid PVC)
Stainless steel 304L
Roughness (RZ)
setting of the pipe internal surface specific rugosity
Rugosity
000,20 mm
Min : 00,00 mm
Max : 99,00 mm
Displayed unit
Adjusting the volume flowrate unit
Determines the physical unit associated with the display of the volume
flow rate. Example: m3/h - l/min...
l/h
Displayed unit
m3/s
m3/min
m3/h
l/h
Measurement config. / Flowrate / Pipe
Fluid
Selecting the fluid to be measured from
Fluid
Fresh water 50°C
Glycol water 5°C
Oil SAE 20
Sea water
Setting the characteristics of the fluid to be measured
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Pipe
Flowrate measurement
Pair of probes
Fluid
Filtering
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Pipe
Flowrate measurement
Pair of probes
Fluid
Filtering
Measurement config. / Flowrate / Fluid
