Ultraflux Minisonic II Portable User Manual

25
Setting up the probes used with the device
Totalizer setting
Probes
Selecting the probe model from a drop-down list
Probes
0SE 1662-10
SE 1515
SE 1815
SE 1790
Ultrasonic path
Choosing the probe fitting mode
Ultrasonic path
Direct (/)
1 reflection (V)
2 reflections (N)
3 reflections (W)
Delta T Zero
Transit time dierence for the sound wave at zero flow. Value entered
automatically with an «Auto Zero», see here
Delta T Zero
+00,50 ns
Min : -300,00 ns
Max : 300,00 ns
Mode
Totalizer mode setting (O, + or -)
Mode
Off
+
-
Weight
Selecting the weight and unit for the totaliser
Weight
1
m3
Measurement config. / Flowrate / Totalizer
Damping
Measurement damping time
Damping
0005 s
Min : 0 s
Max : 3600 s
Memory
Time maintaining last measurement value in case of signal loss
Filtering
Memory
5 s
Flowrate cut o
Threshold of flowrate under which the measurement is forced to zero.
( Display and output)
Flowrate cut off
00000,50 l/h
Min : 0,00 l/h
Max : 1000,00 l/h
Setting up the filtering of the measurement
Measurement config. / Flowrate / Pair of probes
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Pipe
Flowrate measurement
Pair of probes
Fluid
Filtering
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Measurement config. / Flowrate / Filtering
Pipe
Flowrate measurement
Pair of probes
Fluid
Filtering
Menu
Measurement config.
Probes distance
US Signal display
Auto zero
Flowrate measurement
Measurement config.
Logger
Inputs / Outputs
Low power mode
Flowrate measurement
Pair of probes
Fluid
Filtering
Totalizer
(....)
(....)
