Ulvac VD30C - Page 12

YK15-0009-DI-002-04
viii
CAUTION
Be sure to lubricate the machine.
If the lubrication oil came down lower than limit level during operation, it
might give damage on the bearing, gear and shaft
sealing and result in
leak, noise, motor overload and operation stop.
Power Supply wiring <Dismantling>
WARNING
Be sure to cut off the electricity before starting install or dismantling
operation.
Inlet / outlet port piping <Dismantling>
WARNING
① Take off the piping following the Install Manual of the system.
② The Inlet and outlet piping remains very hot while
after having stopped
the Pump.
Be sure to take it off after the Pump has sufficiently cooled down.
③ Make airtight completely the Pump exhaust outlet with a blank flange.
Transfer
WARNING
①
You have a risk of giving damage to your back as the load larger than
safety standard shall be required to transfer this product.
VD30C: 58kg
VD40C: 60kg
VD60C: 90kg
VD90C: 113kg
Be sure to use the loading machinery (such as mobile crane) to lift up
the Pump
or load it on the pallet and fix it and run the Pallet truck for
its transfer.
② Never try to enter beneath the Pump unit when lifted it up.
Use its top eyebolt to load/unloa
d the unit.
