UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 44 -
5.2 Limits for service
Cylinder and Piston unit：mm
Item
S tandard value
Service Limit
Cylinder
Inner diameter of cylinder
Φ52.400～φ52.410
Φ52.5
Cylindricity
0.004
0.10
Flatness of cylinder face
0.03
0.10
Piston, Piston
Ring and
Piston Pin
Outer diameter of piston
Φ52.38～φ52.39
Φ52.3
Inner diameter of piston pin hole
φ14.002～φ14.008
φ14.04
Closure clearance of
piston ring
Top
0.1～0.25
0.35
Second
0.15-0.30
0.4
Oil ring
0.2～0.7
0.85
gap between piston
rings and piston rings
Top
0.02～0.06
0.10
Second
0.02～0.06
0.10
Piston/Cylinder Clearance
0.01～0.03
0.07
Outer diameter of piston pin
φ13.994～φ14
φ13.96
Clearance between piston pin and piston
pin hole
0.002～0.014
0.04
Small End of
Connecting
Rod
Inner diameter
φ14.015～φ14.028
φ14.06
Clearance between small end of
connecting rod and piston pin
0.015～0.03
0.10
Tightening torque of AB bolt: 11N.m
5.3 Troubleshooting
5.3.1. Cylinder pressure is too low or there is no cylinder pressure (performance at low speed is
not acceptable)
• Severely worn or broken piston ring
• Damaged or broken cylinder block or piston
5.3.2. Cylinder pressure is too high. Engine overheats.
• Too much carbon deposit on piston top
5.3.3. Engine oil is consumed significantly, and engine smokes heavily.
• Severely worn or broken cylinder block and piston
• Improper assembly of piston ring
5.3.4. Abnormal noise
• Improper assembly of piston
• Fit clearance is too large between piston and piston pin, and the cylinder block and
piston are severely worn.
