UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 63 -
6.6. Clutch (extraction and installation)
6.6.1. Clutch extraction.
6.6.1.1. Dismantle 4 bolts from end cover of
clutch, then take out end cover of
clutch, bearing, declutch spring.
6.6.1.2. Dismantle locknut and washer of
clutch
6.6.1.3. Take out upper and lower pressure
plate of clutch, drive and driven friction
plates
6.6.1.4. Take out declutch gasket and outer case
of clutch
