UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 98 -
8.7.11. Apply appropriate amount of engine oil onto
fork shaft and insert the shaft into fork hole.
Rotate counter shaft to check if all
components and parts are installed in the
right positions, and main and counter shafts
can rotate freely
8.8. Crankshaft check
8.8.1. Dismantle balanced shaft.
8.8.2. Dismantle crankshaft
8.8.3. Check of crankshaft
Rest crankshaft on V-shaped steel stand. Calibrate
dial gauge to be used for check. Rotate crankshaft
to take the maximum reading change on the
gauge.
Service limit
0.08mm
