UMD NVR User Manual
2
1
Video output
2
Audio output
3
Talkback input
4
Talkback output
5
VGA Interface
6
Network Interface (RJ45)
7
USB Interface
8
HDMI Interface
9
ALARM IN
10
ALARM OUT
11
ALARM GND
12
RS485 Interface
13
Ground
14
Power fan
15
Power switch
16
220VAC inlet
