3.4.3 Select Arbitrary Wave
UTG2000B allows users to output arbitrary waveform in internal or external storage of the
instrument. You can select the arbitrary wave you need with multi-functional knob and direction
key on the interface for using arbitrary wave function or by pressing soft keys
Param →
ArbSel successively.
Note: use multi-functional knob and direction key or press soft keys Param → ArbSel
successively to select storage after inserting U disk into USB interface of front panel, and then select
the arbitrary waveform you need. UTG2000B supports *.csv or *.bsv files with waveform less than
16M points long.
Table 3 - 6 List of built-in arbitrary wave
Common
(15 types)
Engine (25
types)
Blasting vibration “time-vibration velocity”curve
Damped oscillation “time-displacement”curve
Gate self-oscillation signal
Linear frequency modulation pulse signal
Mechanical construction noise
Discharge curve of NI-MH battery
Current waveform of brushless DC motor
