UTG2000B Series 77
3.1.11 Double side band amplitude Modulation (DSBAM)
Select carrier waveform
DSBAM carrier waveform can be sine wave, square wave, ramp wave or arbitrary wave (except DC),
and is sine wave by default. After DSBAM is selected, press the key of basic waveform setting to
quickly set corresponding carrier waveform.
Set carrier frequency
See Carrier wave frequency setting Select modulation source
UTG2000B function/arbitrary waveform generator can select internal or external modulation source.
After you use DSBAM function, you can see that modulation source is internal by default. You can
change it with multi-functional knob on the interface for using DSBAM
function or by pressing Param →
Source
