UNI-T UTG2122B User Manual

UTG2000B Series 121
Symmetry
0.0% ~ 100.0%
Impulse wave
Frequency
1μHz~30MHz
1μHz~25MHz
1μHz~25MHz
resolution
1uHz
pulse width
≥16ns
variable edge
7ns~10s
8ns~10s
9ns~10s
overshoot
<
2% (typical 1Vpp)
shake
150ps
Gauss noise
Bandwidth
120MHz(-3dB)(typical)
80MHz(-3dB)(typical)
60MHz(-3dB)(typical)
DC offset
± 5V(50Ω)
range(peak AC+DC)
±10V (high resistance)
offset accuracy
±(1%+2mV)
Arbitrary wave
Frequency
1μHz~25MHz
1μHz~20MHz
1μHz~15MHz
resolution
1uHz
Wave length
8pts~16Mpts
vertical resolution
16bits(symbol included)
Sampling rage
1.28GS/s(interpolation),320MS/s (DDS mode)
Typical value of minimum
rising/falling time (typical
value)
< 5ns
< 6ns
< 7ns
Shake
150ps (play mode)
Nonvolatile storage
160 waves
Output
amplitude
≤20MHz：1mVpp~10Vpp;(50Ω)
≤60MHz: 1mVpp~5Vpp;(50Ω)
≤120MHz: 1mVpp~2Vpp;(50Ω)
≤20MHz：2mVpp~20Vpp;( high resistance)
≤60MHz: 2mVpp~10Vpp;( high resistance)
≤120MHz: 2mVpp~4Vpp;( high resistance)
accuracy(1kHz
±(1% of set value+1mVpp)
sine wave)
test condition
：
typical value (sine wave,2.0Vpp)
amplitude flatness (equal to
1kHz sine wave,1Vpp/50Ω)
≤10MHz：±0.1dB
≤60MHz：±0.2dB
≤80MHz：±0.4dB
≤120MHz：±0.8dB
waveform output
impedance
50Ω typical value
Insulation
Maximum 42Vpk to ground wire
Protection
channel protection
Modulation types
AM
Carrier wave
Sine wave, square wave(1μHz~30MHz), ramp wave, arbitrary wave
Source
Internal/external
modulation wave
Sine wave, square wave, ramp wave, noise, arbitrary wave
