Uniden DECT1580 User Manual

52
53
Wall Mounting the Base
(To AC outlet)
Wall plate
Removing the wall-mount bracket
A
t the bottom of the base,
pinch the two "nose" of
the wall-mount bracket
as shown, and then
slide the bracket away
from the base.
Place the mounting slots over
the pins on the wall plate.
Slide the base
down to lock it
into place.
Note: Mounting the phone directly on the wall
Be sure the wall is capable of supporting the
weight of the phone, and use the proper type of
anchoring device for the wall material.
Insert two #10 screws (minimum length of 1
3
/
8
inches, not supplied) into the wall, 3
15
/
16
inches
apart.
Leave the screw heads
1
/
8
inch away from the
wall to allow room for mounting the phone.
Align the mounting slots over the screws and
slide the base down into place as shown above.
•
•
•
•

Uniden DECT1580 Specifications

General

Type	DECT telephone
Answering machine	Yes
Phonebook capacity	70 entries
Redial list capacity	5
Call list capacity phonebook	30
Backlight color	Yellow
Frequency band	1.9 GHz
Mac compatibility	No
Product color	Black, Silver
Operating temperature (T-T)	0 - 50 °C
Battery type	BT-1015
Standby time	168 h
Battery capacity	650 mAh
Power supply type	AC/DC
Battery technology	Nickel-Cadmium (NiCd)
Power requirements	AC 120V@60Hz
