MiCard MultiTech4
29
8 Specifications
Model:
 MiCard MultiTech4-P
 MiCard MultiTech4-PI
 MiCard MultiTech4-P LEGIC
 MiCard MultiTech4-P BLE
 MiCard MultiTech4-PI BLE
Power supply:
 4.3 V - 5.5 V via USB
Current consumption:
 RF field on: 120-140 mA typically / Sleep: 500 μA typ. /
Cyclic Operation: TBD
USB connector:
 USB Type A, pre-wired 45 cm (17.7 ") USB cable
Indicators:
 Tri-state LED, dual-tone beeper
Frequency:
 125 kHz/134.2 kHz (LF) / 13.56 MHz (HF)
 2.4 GHz (Bluetooth® Low Energy; BLE models only)
Antenna:
 Integrated
Housing:
 Material: ABS UL94-V0, color: white
Read/write distance:
 Up to 100 mm / 4 inches, depending on environment
and transponder
Transmission speed:
 Host: USB full speed (12 Mbit/s), Air: up to 848 kbit/s
Operating modes (USB):
 USB keyboard emulation – MiCard Protocol (CMFP)
MTBF
 500,000 hours
Dimensions:
 Desktop Reader: 88 mm x 56 mm x 18 mm / 3.5 inch x
2.2 inch x 0.7 inch
Weight:
 Approx. 20 g (without housing)
Temperature range:
 Desktop, Operating: -25 °C up to +70 °C (-13 °F up to
+158 °F)
 Desktop, Storage: -45 °C up to +75 °C (-49 °F up to
+167 °F)
Relative humidity
 5% to 95% non-condensing
Included items:
 MiCard MultiTech4
 Pre-wired USB cable
 Quick start guide
