2. Pre-Installation
2. Pre-Installation
Before installing handsets in a VoWiFi system, ensure that the following equipment is
available:
• Set up chargers and charge the handset batteries before installation.
• Have a number plan available for the handsets.
• Check that the IP addressing plan is set up to support the amount of handsets to be
deployed.
We assume that the VoWiFi system is installed, including some or all of the following
components (depending on system configuration):
• DHCP Server. A DHCP server allows devices to request and obtain an IP address
from a server that has a list of addresses available for assignment. If the WLAN
does not have access to a DHCP server, a list of static IP addresses is necessary.
• Portable Device Manager. The WinPDM is used for administration and
programming of the handsets. All settings and updates are in this case done using
the DP1 Desktop Programmer cradle connected over USB.
• WSG. The WSG handles all communication between the WLAN and its built-in
Device Manager. Before installing the handset, make sure the WSG IP address is
available.
For effective administration of a VoWiFi system with several handsets, it is required to
have both a WinPDM and a Device Manager included in the WSG. In this case, the
WinPDM is only used to allow the handset to access the WLAN system. All other
settings and updates are done with the Device Manager in the WSG.
2.1 VoWiFi System IP addresses
To configure the handsets, enter the IP addresses in the table below.
Table 1.
Device IP address/Number/
Port
Required
IP-PBX If used
WSG If used
Subnet Mask
a
a. Only required if no DHCP is used, that is, static IP is used.
If used
Number plan N/A Yes
NTP Server address
b
b. Depending on system configuration
DNS Server address
a
VoIP settings
c
c. Gatekeeper IP address or SIP proxy IP address used to access the PBX.
Yes
Central Phonebook If used
Syslog server If used
TFTP server If used
Ekahau RTLS
d
d. The IP address and port to the location server.
If used
DHCP range
