Unify OpenStage User Manual

Phone Parameters - Administration Nur für den internen Gebrauch
A31003-S2000-R102-16-7620 02/2016
102 Provisioning Service, Developer’s Guide
c04.fm
Network
4.3.5 QoS
>
With firmware version V3, MLPP capabilities has been added; however, the associ-
ated parameters are not relevant for this document.
WBM Name Item name Type Values Description
Layer 2 qos-layer2 Boolean true/false
Default: true
Enable or disable QoS
layer 2.
Layer 2 voice l2qos-voice Integer 0 to 7
Default: 5
Sets the layer 2 CoS
(Class of Service) value
for voice data (RTP
streams).
Layer 2 signalling l2qos-sig-
nalling
Integer 0 to 7
Default: 5
Sets the CoS (Class of
Service) value for
signaling.
Layer 2 default l2qos-
default
Integer 0 to 7
Default: 0
Sets the default CoS
(Class of Service) value.
Layer 3 qos-layer3 Boolean true/false
Default: true
Activates or deactivates
QoS on layer 3.
Layer 3 voice l3qos-voice Enumer-
ation
0=BE;
10=AF11;
12=AF12;
14=AF13;
18=AF21;
20=AF22;
22=AF23;
26=AF31;
28=AF32;
30=AF33;
34=AF41;
36=AF42;
38=AF43;
46=EF;
56=CS7;
Default: 46
Sets the layer 3 CoS
(Class of Service) value
for voice data (RTP
streams).

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
