Unify OpenStage User Manual

Phone Parameters - Administration Nur für den internen Gebrauch
A31003-S2000-R102-16-7620 02/2016
112 Provisioning Service, Developer’s Guide
c04.fm
System
4.4.4 SNMP
WBM Name Item name Type Values Description
Trap sending
enabled
snmp-traps-
active
Boolean true/false
Default: false
Enables or disables the
sending of a TRAP mes-
sage to the SNMP
manager.
Trap destination snmp-trap-
addr
IP ad-
dress or
host-
name.
Max.64
charac-
ters.
IP address or
hostname.
Default: NULL
IP address or hostname
of the SNMP manager
that receives traps.
Trap destination
port
snmp-trap-
port
Integer Port number
Default: 162
Port on which the SNMP
manager is receiving
TRAP messages.
Trap community snmp-trap-
pwd
Text Default: snmp SNMP community string
for the SNMP manager
receiving TRAP
messages.
Queries allowed snmp-
queries-
allowed
Boolean true/false
Default: false
Enables or disables que-
ries from the SNMP
manager.
Query password snmp-pw Text Any string except
"public", "pri-
vate", "PUBLIC",
"Public", "puBlic"
and other case
related variants.
Password for the execu-
tion of a query by the
SNMP manager.
Diagnostic
sending enabled
diagnostic-
traps-active
Boolean true/false
Default: false
Enables or disables the
sending of diagnostic
data to the
SNMP manager.

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
