4.4.5.2 DSS Settings
4.4.5.3 Free Programmable Keys (FPK)
The function associated with a programmable feature key is represented by a feature id num-
ber. In the provisioning interface, this number is stored as content of the function-key-def
element. The key number is stored in the index attribute, starting from 1 for the first key.
The possible key numbers depend on the OpenStage model:
• OpenStage 15: 1 to 8
• OpenStage 40: 1 to 6
• OpenStage 60: 1 to 8
• OpenStage 80: 1 to 9
• OpenScape Desk Phone IP 35: 1 to 3
• OpenScape Desk Phone IP 55G: 1 to 8
The shifted keys are indexed as follows:
• OpenStage 15: 1001 to 1008
• OpenStage 40: 1001 to 1006
• OpenStage 60: 1001 to 1008
• OpenStage 80: 1001 to 1009
• OpenScape Desk Phone IP 35: 1001 to 1003
• OpenScape Desk Phone IP 55G: 1001 to 1008
In the following example, the repeat dialling function is assigned to the first key:
<Item name="function-key-def" index="1">3</Item>
<Item name="key-label-unicode" index="1">Repeat Dialling</Item>
>
This function is not available with WPI.

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
