Unify OpenStage User Manual

Phone Parameters - Administration Nur für den internen Gebrauch
A31003-S2000-R102-16-7620 02/2016
122 Provisioning Service, Developer’s Guide
c04.fm
System
Forwarding
This is the phone’s built-in forwarding function. An incoming call is forwarded to the predefined
call number, depending on the forwarding type, that is, the current conditions at the phone.
Mute (OpenStage 15 only)
On pressing this key, the microphone is turned off. This programmable key function is available
only for OpenStage 15 phones, which have no fixed mute key.
>
With firmware version V2, server-side forwarding can be assigned to the phone’s
fixed forwarding key; please refer to Section 4.4.5.4, "Fixed Keys".
WBM Name Item name Type Values Description
Key label <n> key-label-
unicode
<index>
Unicode
text.
Max. 24
charac-
ters.
Forwarding Label for the key.
function-
key-def
<index>
Integer 6 Feature ID which defines
the function.
Forwarding type forwarding-
type
<index>
Enumer-
ation
0=Unconditional;
1=No reply;
2=Busy;
3=Immediate-Ex-
ternal;
4=Immediate-In-
ternal;
5=No reply-Ex-
ternal;
6=No reply-Inter-
nal;
7=Busy-External;
8=Busy-Internal;
Default: 0
Call forwarding type.
Destination forwarding-
dest
<index>
Text Default: NULL Destination for call for-
warding.

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
