Unify OpenStage User Manual

Phone Parameters - Administration Nur für den internen Gebrauch
A31003-S2000-R102-16-7620 02/2016
136 Provisioning Service, Developer’s Guide
c04.fm
System
AICS Zip tone
If activated, and a headset is plugged in, the phone will automatically accept incoming calls
without ringing and without the necessity to press a key. Moreover, additional signalling infor-
mation from OpenScape Voice is not required.
To indicate a new call to the user, a zip tone is played through the headset when the call is ac-
cepted.
Available for OpenStage 40/60/80.
Server feature
Invokes a feature on the SIP server. The status of the feature can be monitored via the LED
associated to the key.
WBM Name Item name Type Values Description
Key label <n> key-label-
unicode
<index>
Unicode
text.
Max.12
charac-
ters.
Default: AICS Label for the key.
function-
key-def
<index>
Integer 57 Feature ID which defines
the function.
WBM Name Item name Type Values Description
Key label <n> key-label-
unicode
<index>
Unicode
text.
Max.12
charac-
ters.
Default: Server
feature
Label for the key.
function-
key-def
<index>
Integer 54 Feature ID which defines
the function.
Feature code stimulus-
feature-
code<index>
String Default: NULL This code will be sent in a
SIP INVITE to the SIP
server when the key is
pressed. When a call is
active during keypress, it
is put on hold.

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
