Unify OpenStage User Manual

c03.fm
A31003-S2000-R102-16-7620, 02/2016
Provisioning Service, Developer’s Guide
65
Nur für den internen Gebrauch Basic Communication Procedures
Provisioning Service Driven Interaction
7. Individual client certificate and provisioning server CA certificate(s) have been stored, all
further requests from this device perform mutual authentication on port 18444.
8. When bootstrapping process has finished with success, requests from device via Default
Mode port (18443) are blocked now.
3.6.10.3 Message Flow: Secure Mode, With PIN
The preconditions are:
– Device is not registered, but configured in provisioning service as Secure Mode with PIN re-
quired
– A PIN is configured for this device
Phone Provisioning Service
1 HTTP Request
Reason for contact: start-up
2 HTTP Request
Action: WriteItems
<data items: goto-secure-
mode=’pin’, secure-mode-data,
max-pin-retries>
3 HTTP Response
Acknowledged (HTML)
4 HTTPS Response
CleanUp
5 HTTPS Request (to dls-secure-
port)
Reason for contact: start-up
6 HTTPS Response
Action: ReadItem<bootstrapping-
tan>

Unify OpenStage Specifications

General

Display	Graphical LCD
Connectivity	Ethernet
Supported Protocols	SIP
Power over Ethernet	802.3af (PoE), depending on the specific model
Supported Codecs	G.711, G.729
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Humidity	10% to 90% non-condensing
