Unilumin UTV-P User Manual

Chapter 1 Product Introduction
1.3 Specification
Parameter UTV-P 1.8 UTV-P 2.5
Physical
Parameter
Pixel composition 1R1G1B
LED type 3-in-1 Black SMD
Pixel Pitch 1.8 2.57
Pixels per Cabinet(dots) 320*1080 224*756
Display area(mm) 576（W）*1944（H）*35（D）
Cabinet size (Wx Hx D)(mm) 618（W）*1986（H）*35（D）
Material Aluminum
Weight(kg) 30
Electronic
Parameter
Grey scale(bits) 12
Refresh rate(Hz)
≥1920Hz ≥1920Hz
Frame frequency (Hz) 50/60
Control mode U disk/ Network/ WIFI
Optical
Parameter
Brightness（nits） 600 600
Color temperature(K) 2,000~9,500 Adjustable
Contrast ratio 2500:1 3000：1
Viewing angle(°) 150/140
Electrical
Parameter
Input voltage(V) AC 100~240
Input frequency(Hz) 50~60
Input power
<max>(W/Cabinet)
480
Input power
<typical>(W/Cabinet)
160
Circumstance
Parameter
Storage temperature/
humidity
-20℃~+55℃/10-85%RH
Work temperature/ humidity -10℃~+45℃/10-80%RH
10
