Chapter 9 Troubleshooting and Component Replacement
9.2 Replacement of main Components
9.2.1 Replacement of Module
Step Picture Description
1
Remove the frame fix
part(each one on the top
and bottom)
2
Remove the frame
3
Take out the PC glass
4
Remove the faulty
module and replace with
a new one
61
