1.3. Windows after operation
1.3.1. Icon
① Wi-Fi Status
None
: There is no connected Wi-Fi dongle.
: Wi-Fi connection is not activated
: Wi-Fi connection is activated
② Illumination
Detection
None
: Detect the high illumination status.
: Detect the low illumination status
Menu button
ID input button
Camera video display
Time & Date
Function keys
① Icon for Wi-Fi status
②
② Icon for motion detection
③
③ Warning icon for Fire alarm
④
④ Warning icon for tamper switch
⑤
⑤ Icon for door status
⑥ Icon for network status
⑦Thermal status
