UBio-X Pro2 User Guide 82
UNIONCOMMUNITY Co., Ltd.
Addr : 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu,
Seoul, Korea (zip code: 05836)
Tel: +82-2-6488-3000, Fax: +82-2-6488-3099,
E-Mail :sales@unioncomm.co.kr; http://www.unioncomm.co.kr
- Picture: The image log data is saved in the folder ‘UbioXpro2 / Terminal ID (8 digits) /
log / pictures’ on the SD Card as jpg file.
- Export all: It can export all things User Data, Event Log, and image log to the SD
Card.
▶Import
It copies the data from the SD Card to the terminal.
- User Data: It copies the user DB from the SD Card to the folder ‘unisuser’ in the
terminal.
- System Option: The option setting value of the terminal is copied to the folder
‘UbioXpro2 / config’ in the terminal.
After importing the data, you should reboot the terminal to apply the new DB or setting
value.
▶Others
- Theme: The voice file in the ‘UbioXpro2 /audio’ folder in the SD card is copied to the
terminal.
If you want to replace the authentication success (user_ok.mp3) and the authentication
fail (user_fail.mp3) message with the user voice, set the name of the user voice file as
(user_ok.mp3), (user_fail.mp3) respectively which the user voice will play.
And also the checkbox “User Voice” on [3.7.1. Sound] should be checked.
- F/W upgrade: It upgrades the firmware by the SD Card.
(The firmware should be in the ‘UbioXpro2’ folder on the SD Card.)
If you want to finish working and move to the upper menu, click the [OK] or [BACK]
button.
