17.ABOUT JAPANESE/ENGLISH DISPLAY SELECTION

104

17. ABOUT JAPANESE/ENGLISH

DISPLAY SELECTION

The display language of the F370 is selectable between Japanese and English.

JPN: Japanese

ENG: English

How to set

Setting call Page 2

→
