23.CONFORMITY TO EC DIRECTIVES
119
Attachment of ferrite core
It is necessary to attach a ferrite core to a sensor cable for a load cell or the like.
F370
Load cell
Ferrite core
A cable is bound with a
lock.
Caution
- The F370 main body conforms to EMC directive EN61000-4-5
(lightning surge immunity) in combination with the lightning surge
protect.
- The F370 does not conform to EC directives with the CC-Link option or
Device Net option, and on a DC power source.
