Vision120 OPLC™ User Guide

Figure 13. RS232/RS485 Jumpers,

Factory Default Settings

5. Locate the jumpers

shown in Figure 13,

then change the

jumper settings as

required.

Figure 14. Replacing the Board

6. Gently replace the

PCB board as shown

in Figure 14. Make

certain that the pins fit

correctly into their

matching receptacle.

a. Do not force the

board into place;

doing so may damage

the controller.

7. Close the controller

by snapping the

plastic cover back in

its place. If the card

is placed correctly, the

cover will snap on

easily.
