UAD Powered Plug-Ins Manual - 381 - Chapter 43: SSL E Channel Strip
HMF Q
The Q (bandwidth) control defines the proportion of frequencies surrounding
the band center frequency to be affected by the band gain control. The filter
slopes get steeper (narrower bandwidth) as the control is rotated
counter-clockwise. The available range is 0.5 to 2.5 in both Black and Brown
modes.
Low-Mid
Frequency (LMF)
Band
LMF Gain
This control determines the amount by which the
frequency value for the band is boosted or atten-
uated. The available range is ±15 dB in both
Black and Brown modes.
Tip: Click the “0” to return the control knob to its
center position.
LMF Frequency
This control determines the LMF band center fre-
quency to be boosted or attenuated by the band Gain setting. The available
range is 0.2 kHz to 2.5 kHz in both Black and Brown modes.
LMF Q
The Q (bandwidth) control defines the proportion of frequencies surrounding
the band center frequency to be affected by the band gain control. The filter
slopes get steeper (narrower bandwidth) as the control is rotated
counter-clockwise. The available range is 0.5 to 2.5 in both Black and Brown
modes.
Low Frequency
(LF) Band
LF Gain
This control determines the amount by which the
frequency value for the LF band is boosted or at-
tenuated. The available range is ±15 dB in both
Black and Brown modes.
Tip: Click the “0” to return the control knob to its
center position.
