All rights reserved 44 Service Manual e-Series (EN) 1.1.8
4.1.9 Tool Flange
The tool flange is a Screw Connection and is disassembled like a joint with this connection.
See section 4.1.7 Screw Connection
Power and communication plug is in the same plug.
Connector for power
and Communication
