Universal Robots E Series Service Manual

All rights reserved 59 Service Manual e-Series (EN) 1.1.8
9. Removing the Energy Eater and fan assembly. Remove the four screws.
NOTICE
When assembling, remember to place the round spacers behind the Energy Eater
board.
Fan
Ground – Control Board
Communication – Control Board
48V – Control Board
