3. Insert the key into the ferrite core with snap lock to unlock it and remove it.
4. Remove and discard the two cable ties used for mounting the TeachPendant cables.
5. Press in the clips on both sides of the TeachPendantplug, as illustrated, and pull down to
disconnect from the Teach Pendant port.
6. Fully open/loosen the plastic grommet at the bottom of the Control Box and remove the
TeachPendantplug and cable.
7. Gently remove the TeachPendant cable and TeachPendant.
Service Manual 63 e-Series
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
