Side 22 af 26 UR-FK 2011
Spare parts list
Item number Item designation
08001 Flexolub grease, 1 kg
03011 Screw for grease hole, size 1 joint
03013 Screw for grease hole, size 3 joint
04101 Plastic cover for size 1 joint, includes screws and gaskets
04103 Plastic cover for size 3 joint, includes screws and gaskets
02050 Base plate complete with 6 metres of cable and connectors
02031 Size 3 joint, “Base”
02032 Size 3 joint, “Shoulder”
02033 Size 3 joint, “Elbow”
03003 Screw set for one size 3 joint; 10 x RF M4 screws
02011 Size 1 joint, “wrist 1”
02012 Size 1 joint, “wrist 2”
02013 Size 1 joint, “wrist 3”
03001 Screw set for one size 1 joint or tool; 8 x RF M3 screws.
02040 Tool, complete
04050 Wire set for size 1 joint
04051 Wire set for size 3 joint
04041 Wire set for upper arm
04042 Wire set for lower arm
03105 Flatring for upper arm.
03106 Flatring for Size 1 joint.
03306 Flatring for Size 3 joint.
07753 Fan filter for controller box
