Radial 8, 88, HT Feeders (Dispensing Heads) 49668501 Rev. D
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
Feeder
(Dispensing Head)
Feeder
(Dispensing Head)
Low Parts Sense
Component Lead Conditioner
Reel Bin Holder
For more detailed information on the subassemblies
illustrated, refer to the applicable drawing for that
subassembly located in the Feeders (Dispensing Head)
or Feeder Assembly Drawings section of the maintenance
documentation.
