49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
Align Feeder To Carrier Clip
Care must be used in aligning the feeder to the carrier clip to prevent
damage to the carrier clip.
This adjustment positions the feeder on the sequencer module so the pusher
aligns with the carrier clip.
When properly aligned, the component's leads contact the clamps on the
carrier clip forcing them open at the same time. This action puts equal force
on both leads and prevents the component from twisting as it is being loaded
into the carrier clip.
If the feeder is not correctly aligned to the carrier clip, the clip fails to center
to the pusher when it extends.
Prerequisite Adjustments:
Carrier Clip Alignment to the Cutter Station
Carrier Clip Alignment To Component Transfer Upper Guide
Feeder Preliminary Forward Stroke Adjustment
Machine is powered on and the interlock bypass key switch is turned to the
ON position
Special Tools:
Feeler Gauge Setup Tool
To align the feeder to the carrier clip, perform the following procedure.
WARNING
Operating the machine when the INTERLOCK BYPASS key switch is in
the ON position may be hazardous, and must be performed by qualified
technicians only. The INTERLOCK BYPASS key must be removed before
resuming normal operation.
1. Remove the component carrying cardboard strip from around the feed
wheel.
2. Using IM Diagnostics, zero the chain.
3. Using the Manual Diagnostics window, turn off the main air dump
valve.
4. Manually push the main driver forward as far as it will go.
