Universal Radial 8HT - Anti-Back-Up Dog Adjustment for 15 MM Heads

Page 11
Radial 8, 88, HT Feeders (Dispensing Heads) 49668501 Rev. D
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
Anti-Back-Up Dog Adjustment for 15 MM Heads
This adjustment ensures that the anti-back-up dog engages each tooth of the
ratchet wheel at the end of the return stroke.
This procedure applies to the following 15 mm feeders:
• P/N 50849902
• P/N 50849904
• P/N 52049702
• P/N 51976102
• P/N 51976104
• P/N 51976106
• P/N 52497902
• P/N 52497904
• P/N 52497906
• P/N 52497908
For information about the following 12.7 mm feeders, see Anti-Back-Up Dog
Adjustment for 12.7 MM Heads earlier in this document.
• P/N 50849901
• P/N 50849903
• P/N 52049701
• P/N 51976101
• P/N 51976103
• P/N 51976105
• P/N 52497901
• P/N 52497903
• P/N 52497905
• P/N 52497907
