Universal Radial 8HT - Component Lead Conditioner Adjustment

Page 28
49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
Component Lead Conditioner Adjustment
This adjustment positions the component lead conditioner wheel to
accommodate the selected component, ensuring optimum lead straightening
and reduced occurrence of lead jams.
C
o
m
p
o
n
e
n
t
L
e
a
d
C
o
n
d
i
t
i
o
n
e
r
W
h
e
e
l
1
C
o
m
p
o
n
e
n
t
L
e
a
d
C
o
n
d
i
t
i
o
n
e
r
W
h
e
e
l
2
T
a
p
e
G
u
i
d
e
C
o
m
p
o
n
e
n
t
L
e
a
d
C
o
n
d
i
t
i
o
n
e
r
B
r
a
c
k
e
t
O
u
t
s
i
d
e
T
a
p
e
G
u
i
d
e
Component Lead Conditioner
To adjust the component lead conditioner, perform the following procedure.
Wheel 2
SHCS
1. Loosen the SHCS located on the component lead conditioner wheel 2.
2. Turn wheel 2 either clockwise or counter clockwise to position the
edge of the wheel so that it is even with the component seating plane
(that area of the component which seats on the workboard). Clockwise
rotation is used to increase the height for taller parts. Do not adjust the
wheel close to the body of the component, a gap of .060 inch minimum
is recommended.
Seating
Plane
.060 min gap
.610 inch
(15,3mm)
