49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
8. Remove the machine screws (15) from the cutter holder (16). This
allows the cutter holder to be removed from the housing (5). The
ratchet assembly (29), cam unit (30), pawl (31) and link (22) can all be
disassembled by removing the retainer ring (32) that secures these
parts. The dog (33) and eccentric (34) can be disassembled from the
housing by removing the retainer ring (35) and socket set screw (36)
that secures them.
9. Remove screw (37) from the cutter holder allowing the removal of the
cutter (17).
End of procedure.
Assembling The Feeder
This assembly procedure is included for reference purposes only, and relates
to the disassembly procedures. If the feeder was disassembled further than
described in the previous paragraphs, refer to the drawing package for
detailed information pertaining to that level of disassembly. Reference the
illustrations on subsequent pages to assemble the feeder.
To assemble the feeder, perform the following procedure.
1. Assemble the cutter (17), and cutter holder (16), using screw 37. Install
these parts to the housing (5) using the machine screws (15).
2. Refer to the illustrations for this procedure and assemble the ratchet
assembly (26), cam unit (30), pawl (31), link (22) and associated parts
using the retainer rings (32). Assemble the eccentric (34) and dog (33)
to the housing using the retainer ring (35) and socket screw (36).
3. Ensure that the spacer (37), bearings (38), bushing (39), and spring
washer (40) are properly installed in the housing. Slide the shaft of the
ratchet assembly (29), with the cam unit (30), pawl (31) and link (22)
attached, up through the housing (5). From the top of the housing,
install the retainer ring (28) on the ratchet assembly shaft (29).
4. Install the feed wheel (26) on the ratchet assembly shaft (29). Insert
the locking element (25) into the feed wheel hub, being sure to put the
large half of the locking element on the bottom. Place the clamp plate
(24) over the feed wheel and secure it with the cap screws (23).
5. Hold the main driver (7), with attached molded flag (42), upper pusher
(43), lower pusher (44), and the carrier (12) together. Ensure sure that
the spring pin on the driver rides in the groove in the carrier. Insert the
driver and carrier into the housing. Place 2 nylon washers (41) on the
driver pin (14) then insert the driver pin through the link (22).
