49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
Functional Description
The Feeder Assembly extracts components from reels or ammo packs and
inserts them into the carrier clip on the sequencer chain to be transported to
the insertion head.
The low parts warning and the component lead conditioner are part of the
feeder assembly. The low parts warning assembly signals the need to load
parts when the last taped component from the reel or ammo pack passes
through the sensor. The component lead conditioner straightens the
component leads before they are fed into the sequencer chain.
Maintenance Concept
The preventive maintenance schedule for the feeders is located in the
Preventive Maintenance section in the maintenance support document.
Related Information
The following table defines documents and sources containing information
that may be useful while performing the procedures defined in this docu-
ment.
Document Title Procedure or Section
Preventive Maintenance Preventive Maintenance Schedule - Dispensing Head
Dispensing Head Drawings section All
Prerequisite Information
• Refer to the Preventive Maintenance document for Adhesive and
Lubricant icon information and definitions.
