49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
3. Orient the end of the tape so that the holes in the tape are over the pins
on the component lead conditioner wheel and under the tape guide.
Using the component guard, manually turn the component lead
conditioner wheel until the component tape exits above the assembly.
Component
Reel
Low Parts Sense
Component Lead
Conditioner
Dispensing Head
To Next Page
