49668501 Rev. D Radial 8, 88, HT Feeders (Dispensing Heads)
This document supports Dual, Triple, and Quad Span Feeder Assemblies (Dispensing Heads)
6. With the gate closed, turn the ball plunger in until it bottoms out, then
back it out 1/8 to 1/4 turn. Observe that this mates with an indentation
(detent) in the body of the part and that there is no play in the guide.
7. The low parts warning assembly is secured with a 1/4-20 SBHS, 1/4
FW and 1/4 SLW on a rail that is secured to the sequencer module.
The rail is located just above the reel bin holder assembly.
End of procedure
