Univex 9512 - Figure 7 Electrical Assembly

9512
ELECTRICAL ASSEMBLY
115V, 60HZ, 1PH
100V, 50/60HZ, 1PH
220V,50HZz,1PH
Figure 7
ILLUS. NO. PART NO. DESCRIPTION QTY.
1. 85 12844 MOTOR, 115V, 60HZ, 1PH, 1/2HP,
100V, 50/60HZ, 1PH
1
8512844A MOTOR, 220V, 50HZ, 1PH, 1/2HP
1
2. 8512601 KEY
1
3. 8512602 RUBBER SHOCK ABSORBER 2
4. 8512603 WORM GEAR (115V)
1
8512603A WORM GEAR (220V)
1
5. 8512604 NUT 2
6. 8512605 BOLT, MOTOR 4
7. 8512644 CORK WASHER 4
8. 6509028 WASHER, M8 2
9. 8512617 NUT, M8-1.25 6
10. 8512848 FAN 1
11. 8512931 COLLAR, FAN 1
12. 8512643 CORK WASHER 1
13. 8512612 JOINT 1
14. 851261 1 NUT 2
15. 8512614 NUT, M6-10 2
16. 8512613 SHAFT, SWITCH 1
17. 8512615 KNOB, SWITCH 1
18. 8512616 CAPACITOR, 30MFD, 450V, (100/115V) 2
8512618 CAPACITOR, 10MFD, 500V, (220V) 1
19. 9512101 SCREW, PAN HD M5-0.8 X 10MM 2
20. 9512103 SCREW, PAN HD M5-0.8 X 30MM 1
21. 8512620 RELAY, 115V ONLY 1
22. 7120009 SWITCH 1
23. 9512102 SCREW, PAN HD M5-0.8 X 20MM 3
24. 9512104 ELECTRICAL EQUIPMENT CASING
1
25. 1814069 LAMP, WARNING, 100/115V (NOT SHOWN)
1
1814069A LAMP, WARNING, 220V (NOT SHOWN)
1
26. 8512624 FASTENER, CABLE (NOT SHOWN)
1
27. 4400053 CORD AND PLUG, 100/1 15V (NOT SHOWN)
1
8800210 CORD AND PLUG, 220V (NOT SHOWN)
1
FOR CANADA ONLY
28. IS 14105 CIRCUIT BREAKER 6 AMP (CANADA ONLY)
1
29. 4400227 LABEL, RESET (CANADA ONLY)
1
Page 18
