Univex 9512 - Replacement Parts; Figure 2 Top Casting and Blade Assembly

9512
CASTING and BLADE ASSEMBLY
Figure 2
ILLUS. NO. PART NO. DESCRIPTION QTY.
1. 8512736 CASTING 1
2. 8512203 PIN 2
3. 8512851 STUD 1
4. 8512852 NUT, ACONE M6-1.0 2
5. 9512105 COVER, MOTOR 2
6. 8512859 VENT 1
7. 8512734 PROTECTIVE GUARD 1
8. 8512215 SEAL 1
9. 8512216 SEAL, O-RING 1
10. 8512229 SCREW, FLAT HD M5-0.8 X 12MM 3
11. 8512729 ROD, CUTTER SUPPORT 1
12. 8512218 RETAINING RING 1
13. 8512220 GEAR (For 115V) 1
8512220A GEAR (For 220V) 1
14. 8512730 SUPPORT, BLADE, INCLUDES 9 THRU 19 1
15. 8512731 SPACER, BEARING 1
16. 1030019 BEARING 2
17. 8512225 RETAINING RING 1
18. 8512226 BUSHING, TAPERED 1
19. 8512227 SEAL 1
20. 8512230 GUARD, KNIFE 1
21. RESERVED
22. 8512228 BLADE 1
23. 8512234 FENCE 1
24. 8512732 SUPPORT, FENCE 1
25. 8512237 SET SCREW 1
26. 6509080 STUD, FENCE ADJUSTING 2
27. 6509081 ACORN NUT, M8 2
28. 6509098 SET SCREW, M6-1.0 X 10MM 1
29. 8512214 SET SCREW, M6-1.0 X 16MMB 1
30. 7510084 KNOB, GRADUATED 1
31. 8512208 GRADUATED KNOB BUSH 1
32. 8512209 RIVET 2
33. 8512210 FRONT WHEEL 1
34. 8512211 REAR WHEEL 1
35. 6509024 KNOB, GUARD ATTACHMENT 1
36. 8512206 DOWEL PIN 1
37. 8512733 DEFLECTOR 1
38. 9512106 BRACKET, LEG 4
39. 9512108 SCREW, FLAT SOC HD M8-1.25 X 20MM 4
40. 8512248 LEG 4
41. 8512855 FOOT 4
42. 9512107 COVER, BOTTOM 1
43. 7510067 SCREW, SOC HD CAP M6-1.0 X 20MM 4
44. 8512231 ROD, KNIFE GUARD 1
45. 8512232 LAMA 1
46. 8512233 KNOB, KNIFE GUARD 1
47. 7510012 SPACER .81 ID X 1.18 OD X 12MM 1
48. 8512735 SCREW, SOC HD M5-0.8 X 25MM 4
49. 4400339 LABEL, MAX ( NOT SHOWN) 1
Page 12
