30
1
LEVELING THE BASE
1 Place the base on the vehicle seat with the adjustment
foot toward the vehicle seat back.
2 Press the level adjust button on the top of the base
to extend the foot and change the recline angle. Check
the angle indicators on either side of the base. The base
is level when only the GREEN marker is visible between
the two arrows. No RED should be visible.
LEVEL WHEN
NO RED
VISIBLE
LEVEL WHEN
NO RED
VISIBLE
NOTE: Vehicle must be parked on a level surface to
properly level the base.
2
If proper angle cannot be achieved
with adjustable foot, a rolled towel
may be used. Foot must be in fully
extended position.
BASE INSTALLATION WITH VEHICLE SEAT BELT
