CARE + MAINTENANCE – Seat Padding Removal
1 Remove buckle cover.
2 Remove (4) plastic tabs from front sides of carrier.
3 Loosen padding from front end of carrier and free padding
from around harness adjuster release button housing.
4 Raise SIP to highest position and pull back padding panel. Slide SIP to lowest position and
release (8) plastic tabs from upper portion of carrier.
1 2 3
4
